Multi-function Lnk Wheel Printing And Sealing Machine CFR-1000V
Multi-function Lnk Wheel Printing And Sealing Machine CFR-1000V
This sealing machine is suitable for sealing package bags made of various film such as plastic film, aluminum foil and complex film etc. It is can print the manufacturing date, batch number and expiry date by solid-ink at the same time. It is widely used in pharmaceutical, food, dairy use and other packaging industries.
This sealer adopting electronic thermostat control unit and step-less speed-regulating transmission mechanism, can seal various plastic film bags made from different materials and can also be equipped with varied packaging production lines. The machine has no limitation on sealing length, characterized by high efficiency in continuous sealing, reliable sealing quality, rational structure and convenient operation etc.
After the product is sealed and packaged by this machine, it has a beautiful appearance, clean, dust-proof, moisture-proof, anti-breakage, easy to handle and store. It greatly reduces product loss and has packaging cost advantages.
Remarks
- Sealing belts are oriented horizontally to allow for easy access and high throughput
- Max loading weight of 3 KGS is ideal for most consumer good.
- Sealing speed and temperature adjustable with film thickness to ensure sealing quality.
- Electronic constant temperature mechanism.
- Stepless speed regulating transmission motor.
- Flexible height and wide changed with packet size.
| Model | CFR-1000V |
|---|---|
| Sealing width | 6-12mm |
| Sealing length | 0~Limitless |
| Sealing speed | 0-12m/min |
| Printing category | Steel wheel printing |
| Conveyor load | Max. 3kg |
| Temperature range | 0~300°C |
| Power | 750W |
| Voltage | 220V 50Hz/110V 60Hz |
| Machine size(L x W x H) | 908*390*290mm |
| Net weight | 27kg |
